S18 Rail

The S18 light steel rail is a versatile industrial solution compliant with DIN 5901 standards, designed for light-to-medium duty applications. Available in Q235B low-carbon steel (cost-effective for general use) and 55Q high-carbon steel (wear-resistant for heavy loads), this 18.3kg/m rail balances strength and flexibility. With dimensions optimized for stability (93mm height x 82mm base), it excels in industrial track systems, warehouse logistics, and material handling environments.

Specifications of S18 Rail:

Size: S18 / S18 light steel rail
Length: 5~12m or other length according to customers’ requirement
Material: Q235B,55Q
Standard: DIN 5901
Type: Light Rail
Rail Height: 93mm
Bottom Width: 82mm
Web Thickness: 10mm
Head Width: 43mm
Weight: 18.3kg/m

S18 Rail Material Parameter

Choose Q235B (ductile, corrosion-resistant) for general logistics or 55Q (tensile strength ≥685MPa) for heavy-duty wear, both compliant with DIN 5901.

Applications of S18 Rail

The S18 light rail is ideal for diverse industrial scenarios:

Construction & Mining

Serves as temporary tracks for construction machinery in building projects. Functions as auxiliary haulage rails in small-scale mining operations for equipment transport.

Industrial Track Systems

Ideal for internal transport in manufacturing plants, supporting material handling carts and conveyor systems. Suited for low-to-medium load scenarios requiring flexible track layouts.

Port & Yard Operations

Used in ports for light cargo transport rails and temporary storage yard tracks. Supports routine loading/unloading operations with reliable structural stability.

Warehouse & Logistics

Perfect for warehouse crane rails and forklift guidance tracks, enhancing operational efficiency in distribution centers. Designed for smooth cargo movement and equipment positioning.

Advantages of Our S18 Rail

International Standard Compliance

Meets DIN 5901 specifications for dimensional accuracy and mechanical properties, ensuring compatibility with global industrial track systems.

Dual Material Versatility

Q235B offers excellent formability and cost efficiency for general industrial use. 55Q provides higher tensile strength (≥685 MPa) and wear resistance for demanding medium-load applications.

Cost-Effective Performance

18.3kg/m lightweight design reduces transportation and installation costs, while standardized production ensures competitive pricing without compromising durability

Easy Installation & Maintenance

Compact profile and balanced weight enable efficient on-site handling, while the robust 10mm web thickness reduces deformation under repetitive loads.

Customization Services

Glory Rail offers tailored solutions to meet specific project requirements:

Length Customization： Rails can be precision-cut to any length between 5–12m (or beyond) to fit unique track layouts and installation needs.
Surface Treatments： Hot-dip galvanization for corrosion resistance in coastal or high-humidity environments. Anti-wear paint coatings to extend service life in abrasive industrial settings.
Pre-Machining Options： Pre-drilled bolt holes for seamless track connection. Miter cuts or curved sections for specialized track configurations.

High-Performance Rail Components

Designed to reduce vibration, align tracks, and support dynamic rail operations.

Request a Tailored Quote

To get a quote for S18 light rails, please provide:

Quantity required
Material preference (Q235B/55Q)
Desired length (standard/custom)
Application scenario (e.g., warehouse, industrial track)

Experience reliable, DIN 5901 S18 light rails. Contact us today!
